Automatic photo mark tracking;
Positioning stop.
1. Using three servo motors ensure the precise synchronization of product feeding, film feeding, clamping conveying,sealing and cutting.
2. It is convenient for changing products, can reach many purposes with one machine.
3. Using cantilever structure, timing belt drive,designed for convenient maintance, low running noise and smooth running.
4. Simple operation by using large touch screen panel. It can save and call out settings for different package to simplify changing products.
5. Using flexible clamping system for product feeding, reduce waste.
6. Hygienic designed for the chain guide rail, avoid product residuals staying in the rail.
7. Using new type double back sealing system and heating structure,achieve excellent sealing under low temperature and high speed.When the machine stops,its hot sealing wheels open automatically , to avoid burning film
Max Film Width | ≤450 mm |
Packaging Speed | 30~110 bag/min(depends on product dimension) |
Cutting Length | 90≤L≤400mm |
Packaging Width | 35≤W≤120mm |
Packaging Height | 5≤H≤60mm |
Total Power | 110V—380V |
Total Weight | Around 1050kg |
Dimension | Around 4300mm×1350mm×1960mm |
Temperature Can Be Controlled Within | ±2 ℃ |
Photo Mark Tracking Tolerance | ±2mm |
Cutting Length Ttolerance | ±2mm |
